These Relay Pin Brass Terminals are made from premium brass via precision stamping. They deliver good conductivity and corrosion‑resistant durability for stable relay connections. Custom specifications are supported for automotive, industrial automation, telecom, and home‑appliance electrical systems.
Send Inquiry
What is the Relay Pin Brass Terminal?





Relay Pin Brass Terminal is a stamped conductive component designed to provide electrical connection and mechanical positioning within relay assemblies. Manufactured from brass sheet through precision stamping and forming, the terminal serves as an interface between relay internal conductors and external circuit connections. Its pin profile, contact geometry, thickness and mounting dimensions directly affect insertion fit, electrical contact conditions and assembly consistency. Custom brass relay terminals are available for OEM and wholesale projects according to customer drawings, samples and specified material requirements. Production parameters can be established around the relay housing structure, terminal arrangement and electrical operating conditions.

Relay Pin Brass Terminal

Precision Stamping & Structural Integrity of Sheet Metal Brass Stamping


Progressive Die Stamping Capability

Our factory utilizes high-speed press machines operating with multi-cavity progressive dies to manufacture relay pin brass terminals with repeatable precision. Tooling design incorporates burr-control stations to maintain burr heights under 0.02 mm, preventing plastic housing damage during pin insertion.

Elasticity & Retentive Force Control

By managing cold-work hardening ratios during the stamping process, the half-hard C2680 brass material retains optimal yield strength. This ensures terminal pins maintain consistent retention force when mated with PCB sockets, preventing contact relaxation under thermal cycling.

Custom Pin Profiles & Geometry

We fabricate square, flat, stepped, and notched pin profiles directly from customer drawings. Whether required on continuous reel strips for auto-insertion machinery or as loose-piece components, our tooling engineers adapt die layouts to meet exact terminal geometry specifications.

High-Volume Production Line Integrity

Optical inspection systems monitor real-time pitch dimensions and terminal flatness across high-volume production runs. Scrap sensors prevent double-stamping and die damage, guaranteeing batch-to-batch consistency for critical electrical components.

Types and Characteristics of Stamping Process for Relay Pin Brass Terminal







Application-Specific System Integration of Brass Sheet Metal Stamping Parts

Automotive Electrical Relays

Engineered to handle vibration, shock, and thermal swings in 12V and 24V DC automotive starter relays, horn controls, and radiator fan control modules.

Smart Meter & Latching Relays

Optimized for low contact resistance in energy meter latching mechanisms where low power loss and high continuous current handling are essential.

Industrial MCCB & Power Switches

Serve as terminal connectors in industrial control relays, circuit breakers, and magnetic starters operating under demanding AC-3 and AC-4 switching conditions.

Home Appliance Controllers

Designed for reliable press-fit and wave soldering in printed circuit board relays for washing machines, air conditioners, and induction heating equipment.

Applications of Relay Pin Brass Terminal



Frequently Asked Questions about Electrical Contact Stamping Brass Parts Custom


Why is brass used for relay pin terminals instead of ordinary steel?

Brass provides electrical conductivity and forming characteristics suitable for relay connection components. Ordinary steel has substantially different electrical properties and may require additional conductive treatment.

How do you prevent burrs on the sheared edges of Brass Metal Stamping Parts Electrical Accessories Components?

We utilize micro-clearance progressive stamping dies combined with inline carbide trimming stations. This keeps edge burr height strictly within ≤ 0.02 mm, preventing plastic housing scraping during automated terminal insertion into relay bases.

What dimensional tolerances can your progressive tooling maintain?

Our high-speed stamping presses maintain pitch and width tolerances of ±0.01 mm, and material thickness tolerances of ±0.008 mm. Critical dimensions are continuously monitored via inline optical vision systems during production runs.

What is the typical lead time for custom brass terminal stamping tooling?

Progressive die design, fabrication, and initial T1 sample submission typically require 10 to 15 business days. Upon sample approval and dimensional inspection, full production orders ship within 10 to 15 business days.

Brass Strip for Relay Pin Brass Terminal







Submit your engineering drawings or material specifications today to receive a factory-direct quote on custom Relay Pin Brass Terminal manufacturing within 24 hours.
