Products Description
The Relay Yoke Stamping Parts are a typical precision metal functional structural component. Its core function is not simply support or fixation, but rather participation in the complete magnetic circuit construction of the electromagnetic system. The yoke, through its precise geometry, guides the magnetic flux path, enabling the efficient closure of the magnetic field generated by the electromagnetic coil, thereby achieving the relay's engagement, release, and cyclic stability.
In practical applications, the yoke stamping undertakes multiple tasks:
Constructing a stable and low-loss magnetic circuit framework
Ensuring the consistency of movement between the moving and stationary iron cores
Providing assembly reference surfaces and dimensional control references
Improving electromagnetic response speed and operational consistency
Therefore, the design and manufacturing precision of the yoke directly affects the relay's operating current, holding force, and fatigue life.
Production Process: Refined Management Throughout the Entire Lifecycle
Precision Shearing
Ensuring the grain direction of the raw material aligns with the magnetic circuit direction.
Multi-Station Forming
Achieving complex geometric shapes while maintaining structural strength through bending, extrusion, and shaping processes.
Vacuum Hydrogen Annealing (Core Process)
High-temperature annealing under a controlled atmosphere removes impurities such as carbon and nitrogen, restoring the magnetic properties damaged by stamping.
Surface Treatment
Providing environmentally friendly electroless nickel, bright tin, or zinc-iron alloy plating, offering both corrosion resistance and ensuring weldability and assembly performance with other Magnetic Yokes.
Design Advantages: Topology Optimization and Simulation-Driven Design
| Magnetic Circuit Simulation Optimization Design | Leveraging advanced electromagnetic simulation software, we assist clients in optimizing the geometry and topology of the Relay Yoke Neck. By simulating the distribution of magnetic field lines, we can identify magnetic saturation regions and optimize by increasing thickness or changing shape, thereby achieving lightweight and miniaturized designs while maintaining magnetic performance. |
| Universal and Customizable Mounting Interfaces | For different types of relays (such as general-purpose power relays, automotive relays, and magnetic latching relays), we have designed standardized mounting holes and snap-fit structures. Simultaneously, for clients' specific base structures, we offer rapid customization services, achieving a perfect fit by adjusting bending height and hole coordinates, reducing assembly difficulty for clients. |
| Anti-Misalignment Design | On complex automated assembly lines, misalignment of parts is fatal. We have designed anti-misalignment bumps or asymmetrical notches in the non-functional areas of the Relay Coil Yoke to ensure that automated robots can accurately identify the direction, preventing reverse assembly and improving the efficiency of clients' production lines. |
Application Advantages: Adaptable to diverse electromagnetic environments
Automotive Relays
Meets automotive-grade vibration requirements, exhibiting excellent mechanical fatigue resistance in the engine compartment and cockpit electronics.
Industrial Automation
Yoke Metal Parts of Relays provide high-sensitivity magnetic circuit support for miniaturized relays within PLC control modules and frequency converters.
New Energy Field
High-voltage DC relays (HVDC) utilize a large-size, high-flux Yoke Mount Kit for Relay design to assist in achieving reliable arc extinguishing effects.
contact us
If you require matching and optimization for your relay structure, magnetic circuit design, or automated assembly scheme, please submit your technical drawings and application requirements. We will provide professional support from the perspectives of engineering feasibility and long-term reliability.
