Tungsten Contacts for Electrical Appliances

Tungsten Contacts For Electrical Appliances are precision components specifically designed for high-load, high-frequency electrical switching applications. The core consists of a high-purity tungsten sheet and highly conductive rivets bonded together using an advanced high-temperature brazing process. The surface undergoes multi-layer nickel plating to ensure long-term stability and corrosion resistance. This product series is optimized for applications such as automotive and motorcycle horn systems and smart home relays, providing a full range of solutions from economical to high-performance to meet the electrical contact needs of customers in various industries.

Send Inquiry

Products Description

Tungsten Contacts For Electrical Appliances, with their unique material combination and precision manufacturing process, are an ideal choice for medium and high voltage electrical applications. This product is specifically designed for high-frequency switching equipment such as horns and relays. The head uses a high-purity tungsten sheet, and the feet are fitted with iron rivets (economic type) or copper rivets (high-performance type). A stable connection is formed through a high-temperature brazing process, and the surface is covered with a nickel plating layer to prevent oxidation, achieving the core advantages of high temperature resistance, arc resistance, and low contact resistance.

Product Nature and Core Features

Head

Made of high-purity sintered tungsten sheet (W≥99.5%), possessing an extremely high melting point (3422°C) and excellent resistance to arc erosion for Car Horn Tungsten Contact Rivets.

Feet

Depending on customer requirements, iron rivets (economic/low-end solution) or copper rivets (high-performance/mid-to-high-end solution) can be selected to ensure good conductivity and assembly compatibility for Industrial Tungsten Brazed Contacts Rivets.

Connection Method

A strong metallurgical bond between tungsten and metal rivets is achieved through high-temperature vacuum brazing technology, eliminating the risk of incomplete soldering and delamination for Tungsten Contact for Circuit Breaker.

Surface Treatment

The entire surface is nickel-plated, effectively isolating air and moisture, significantly improving oxidation and corrosion resistance, and extending service life.

Tungsten Rivet for Electric Horn

Detailed Showcase

Microstructure

The welding interface between the tungsten sheet and the rivet exhibits a dense metallurgical bond, free of pores or cracks, for Tungsten Rivet for Electric Horn.

Surface Treatment

The nickel plating layer has a uniform luster, feels smooth to the touch, and exhibits only slight discoloration after salt spray testing for Tungsten Contact for Circuit Breaker.

Packaging Protection

Anti-static vacuum packaging is used for Industrial Tungsten Brazed Contacts Rivets, with every 100 pieces individually separated to prevent damage to the plating during transportation.

Tungsten Contacts For Electrical Appliances Details Show

Application Areas

Automotive and Motorcycle Horns

Maintains stable performance in extreme temperatures ranging from -40℃ to 125℃, solving the horn malfunction problem caused by the easy melting and soldering of traditional copper contacts for Car Horn Tungsten Contact Rivets.

Smart Home Relays

Compatible with PLC control systems, supporting over 100,000 fault-free switching cycles, meeting the long-term use needs of smart door locks, lighting, and other devices for Industrial Tungsten Brazed Contacts Rivets.

Industrial Control Equipment

Suitable for high-voltage scenarios such as contactors and circuit breakers, replacing silver-based contacts to reduce costs while improving arc resistance for Tungsten Contact for Circuit Breaker.

Tungsten Contacts For Electrical Appliances Application
