In high-voltage systems such as electric vehicle battery packs, energy storage converters, and DC fast charging stations, high-voltage DC relays play a crucial role in connecting and disconnecting DC circuits of hundreds or even thousands of volts. To ensure that the arc generated when the contacts break is effectively extinguished and to maintain the insulation withstand voltage between the contacts over a long period, these relays generally adopt a sealed cavity structure filled with a high-pressure hydrogen or nitrogen mixture. The airtightness of the High Temperature Metallized Ceramic Relay Case essentially determines the long-term stability of the relay's insulation performance. Once a slight leak occurs in the cavity, the originally tightly isolated insulation environment will slowly deteriorate, posing a potential threat to equipment and system safety.
Alumina Relay Ceramic Envelope for Electric Automobiles is typically constructed by metallizing and welding an alumina ceramic ring to a metal end cap and base plate, forming a sealed space completely isolated from the external atmosphere. The internal inert or reducing gas environment not only effectively extinguishes the arc, but more importantly, provides a stable and high-dielectric-strength insulating medium. Under-rated operating voltage, the contact gaps, and the distance between the contacts and the housing rely on the surface distance between the gas medium and the ceramic inner wall to withstand the voltage. This sealed structure resists direct corrosion of the insulation by external moisture, salt spray, and conductive dust, allowing the relay to maintain high insulation resistance and withstand voltage levels even under automotive-grade temperature fluctuations and mechanical vibration conditions.
Air leakage in the cavity usually originates from tiny cracks at the ceramic-metal sealing interface or the expansion of weld pores under thermal cycling stress. Initial leakage is extremely low, and gas exchange may only occur when there are drastic changes in external air pressure or temperature. Once a seal failure occurs in an EV Alumina Ceramic Housing, external air will intrude, leading to a gradual deterioration in the composition and purity of the internal gas. The entry of oxygen and moisture is a direct cause of decreased insulation performance. Water molecules adsorb onto the ceramic inner wall and the surface of the contact insulation, forming a weakly conductive water film. This significantly reduces the surface insulation resistance. Moisture infiltration can also cause the insulation separator between high and low voltage components to absorb moisture, further lowering the creepage resistance.
The presence of oxygen makes the silver alloy or copper-based materials of the contacts more prone to oxidation under the high temperature of the breaking arc. The resulting metal oxide particles sputter and adhere to the ceramic inner wall. The accumulation of conductive particles can create potential leakage paths within the cavity, potentially leading to flashover or breakdown during insulation withstand voltage testing. Once the seal integrity of an EV Alumina Ceramic Relay Housing is compromised, the insulation performance undergoes a gradual and irreversible decline, continuously affecting the relay's operational reliability and lifespan.
Because the interior of the cavity is not visible, initial leaks are difficult to detect with a macroscopic appearance. Therefore, high-sensitivity helium mass spectrometry leak detection is typically used in production and quality control to confirm the seal performance and detect trace amounts of gas leakage. For relays already in operation, regular insulation resistance testing is a crucial method for identifying potential sealing issues. Under the same temperature and humidity conditions, if the insulation resistance between contacts or between contacts and the base shows a continuous decreasing trend, and external factors have been ruled out, it can be determined that the Metallized Alumina Ceramics for Electrical Components have an internal seal failure risk.
In actual operation, if the relay's casing temperature is significantly higher than that of similar products when disconnecting the same load, the internal gas medium has likely deteriorated, leading to reduced arc extinguishing efficiency and the conversion of excess arc energy into heat. In this case, preventative replacement should be arranged promptly to avoid insulation breakdown, causing high-voltage grounding or short-circuit accidents. The Metalized Ceramic Insulating Tubes Metalizating Ceramic Part is the core line of defense for ensuring the long-term insulation capability of high-voltage DC relays. When selecting products, the reliability of the sealing process should be given priority. During operation and maintenance, an insulation resistance trend monitoring mechanism should be established to control the insulation risks caused by seal failure at an early stage, effectively ensuring the safe and stable operation of new energy high-voltage systems.
Our self-developed and manufactured High Temperature Metallized Ceramic Relay Case, relying on mature metallization welding technology, boasts excellent sealing performance and can withstand severe temperature changes and mechanical vibrations. It effectively avoids problems such as air leakage and insulation degradation, perfectly meeting the application requirements of various high-voltage DC relays.
