Precision‑stamped cold‑rolled steel (CRS) for Relay EMI Shield Cover provides electromagnetic compatibility (EMC) isolation and structural rigidity for high‑density power relays, ensuring magnetic containment with dimensional stability of CpK ≥ 1.33 across million‑piece volume production.
Material Characteristics & Metallurgy of Cold Rolled Steel in Sheet Metal Relay Cover
Cold‑rolled steel used for Sheet Metal Relay Covers and enclosures is manufactured via continuous cold reduction of pickled hot‑rolled coils below the recrystallization temperature. This cold‑working process eliminates surface scale, yielding tight thickness tolerances, smooth surface textures, and uniform mechanical properties required for complex progressive die stamping.
In accordance with national standard GB/T 710‑2008 (equivalent to commercial cold‑rolled carbon steel sheet specifications), commercial grades include SPCC, SPCD, and SPCE. Selecting the correct grade dictates the formability and structural integrity of the Stamped Metal Cover during high‑speed stamping operations.
| Steel Grade | Tensile Strength (Rm min, MPa) | Elongation (A min, %) | Primary Application in Relay Components |
|---|---|---|---|
| SPCC (Commercial) | 270 | 32 | Standard relay outer enclosures, flat covers, and basic rectangular shielding cans. |
| SPCD (Drawing) | 270 | 36 | Deep‑drawn relay shield cans requiring moderate flange forming and corner radii. |
| SPCE (Deep Drawing) | 260 | 40 | Complex integrated PCB relay EMI shields with deep draws and multi‑stage locking tabs. |
Quality Control Metrics and Salt Spray Performance Standards of Precision Stamped Shield Cover
Qualifying cold‑rolled steel for high‑reliability electrical relay applications requires strict adherence to physical and surface criteria. Surface integrity must remain free from micro‑scratches, indentations, and laps to prevent localized magnetic flux leakage and non‑uniform passivation adhesion.
To withstand aggressive industrial operating environments, Precision Stamped Shield Covers undergo chemical passivation or electrostatic powder coating. Certified finished parts achieve > 500 hours of neutral salt spray resistance complying with ASTM B117, preventing red rust formation and degradation of magnetic isolation performance over a 15‑year operational lifecycle.
Dimensional repeatability is maintained using automated optical inspection (AOI) coupled with statistical process control (SPC). Stamping press parameters are regulated to maintain bending angle tolerances within ±0.5° and hole pitch accuracy within ±0.005 mm, guaranteeing seamless mechanical integration into Powder Coated Metal Housing.
Consult Our Electrical Engineers Today
Engineering Advantages in High‑Volume Relay Manufacturing
Utilizing Relay Shield Cover balances magnetic permeability, mechanical strength, and cost‑efficiency. Compared to austenitic stainless steel, low‑carbon cold‑rolled steel offers favorable magnetic shunt properties, effectively attenuating stray magnetic fields generated by high‑current switching contacts in automotive and industrial relays.
During progressive stamping, springback compensation algorithms are engineered directly into the tool design to account for material yield strength variations. This ensures that locking tabs and grounding flanges maintain consistent clamping force against relay bases, preventing micro‑vibrations and contact chatter under high‑vibration profiles governed by IEC 60947.
contact us
We deliver high‑precision Relay EMI Shield Cover solutions. Submit your drawing and load‑condition requirements to obtain test reports and formal quotations for custom shielding assemblies.
