Metallized welded ceramic housings: What role does brazing technology play in this field?

Sep 12, 2026 Leave a message

Metallized Welded Ceramic Housings require precise engineering to join high-dielectric ceramics with conductive metals, forming the structural core of EV high-voltage DC contactors and aerospace power systems. By utilizing advanced vacuum brazing and active metal brazing (AMB) techniques, manufacturers achieve hermetic seals with shear strengths exceeding 120 MPa, ensuring thermal and electrical stability under extreme operational loads.

Metallized Welded Ceramic Housing



Why Ceramic Metallization is Engineered for Power Electronics

Raw engineering ceramics such as Al₂O₃ and AlN offer exceptional electrical insulation and high breakdown voltages, but their inherent brittleness and zero electrical conductivity prevent direct assembly with metal components. Metallization applies a uniform, tightly adherent metal film to the ceramic substrate, bridging the physical gap between dissimilar materials.

Property / Parameter Unprocessed Ceramic (Al₂O₃) Metallized Ceramic Substrate
Volume Resistivity > 10¹⁴ Ω·cm Variable at interface
Thermal Conductivity 25 - 30 W/m·K Enhanced heat dissipation
Peel / Shear Strength N/A ≥ 120 MPa
Hermetic Leak Rate Dependent on body < 1 × 10⁻⁹ Pa·m³/s



Metallized Welded Ceramic Housing Raw Materials



The Mechanics of Brazing Technology for DC Relay Elements Metallized Ceramics

Brazing operates fundamentally differently from fusion welding by utilizing a filler metal with a liquidus temperature above 450°C but strictly below the solidus temperature of the base materials. Capillary action draws the molten filler alloy into tight microscopic clearances (0.02 mm - 0.05 mm), creating a continuous, stress-distributed joint without melting the parent ceramic or metal components.



Dual Operational Modes in Ceramic Joining



Mode 1: Traditional Brazing for Pre-Metallized Ceramics

In conventional assemblies, the Precision Metallized Ceramics undergo prior metallization via thin-film methods (such as magnetron sputtering) or thick-film methods (such as the molybdenum-manganese/Mo-Mn process).

  • Interface Preparation: The ceramic surface receives a fired Mo-Mn layer followed by an electroplated nickel layer (≥ 3 μm) to act as a wetting base.
  • Filler Application: Ag-Cu base filler alloys (e.g., Ag72Cu28) are positioned between the nickel-coated ceramic and copper or Kovar hardware.
  • Thermal Cycle: Processing occurs in a controlled vacuum furnace (10⁻³ Pa) at temperatures ranging from 780°C to 850°C.



Mode 2: Active Metal Brazing (AMB) as an Integrated Solution

Active Metal Brazing eliminates the need for separate pre-metallization steps by introducing active reactive elements directly into the filler alloy.

  • Alloy Composition: Silver-copper filler metals are alloyed with active transition elements, most commonly Titanium (Ti) at 2% to 4%.
  • Reaction Mechanism: During high-temperature vacuum heating, titanium atoms segregate to the ceramic interface, chemically reacting with Al₂O₃ or AlN to form a continuous titanium reaction product layer.
  • Performance Advantage: This monolithic reaction zone provides exceptional thermal shock resistance, making AMB indispensable for high-power insulated-gate bipolar transistor (IGBT) modules and high-frequency EV inverter substrates.

Consult Our Electrical Engineers Today



Production Technology and Application of Metallized Welded Ceramic Housing



Why Brazing Remains Irreplaceable in High-Strength Metallized Ceramic Components

Mechanical Joint Integrity: Controlled capillary filling distributes mechanical loads evenly across the joint area, preventing stress concentrations that cause micro-fractures during thermal cycling (-55°C to +150°C per IEC 60068-2-14).



Thermal and Electrical Continuity: High-purity silver-copper braze joints maintain low electrical contact resistance (≤ 0.1 mΩ) and efficient thermal pathways for heat dissipation.



Hermetic Sealing: Brazed Ceramic to Metal joints achieve helium leak rates below 1 × 10⁻⁹ Pa·m³/s, safeguarding sensitive internal components from moisture, oxidation, and particulate ingress in compliance with IP67/IP69K ratings.



Dimensional Precision: Processing temperatures below parent melting points limit thermal distortion, keeping dimensional tolerances within ±0.02 mm.

Industrial Application Ecosystem of EV Alumina Ceramic Housing

New Energy Vehicles (EV/HVDC): High-voltage DC contactor arc chambers, ceramic switch housings, and fast-charging power module substrates operating up to 1000V DC.



Aerospace and Defense: Satellite power distribution components, radar vacuum tubes, and hermetic feedthroughs requiring extreme vibration and thermal shock resistance.



Power Semiconductors: Direct Bonded Copper (DBC) and AMB ceramic substrates for wind turbine inverters and industrial motor drives.

Metallized Welded Ceramic Housing Application Detail Diagram
